The ring die is an important spare part of the pellet machine. Since the loss of pellet mill ring die accounts for more than 25%-30% of the maintenance cost, some users purchase low-priced ring dies. As a result, the price is reduced, but the ring die amount is increased, and production efficiency has dropped, the overall cost of production has increased. This situation is very common.

Precautions for buying pellet mill ring die:

At present, there are many pellet machine manufacturers in China, the competition is fierce, and ring mold quality is uneven, so it is very important to choose a ring die suitable for your machine. When buying a pellet machine ring die, you need to pay attention to the following:

1. Ring die material selection

The ring die material of the pellet machine is generally made of alloy steel or stainless steel. Aquatic animal feed, fertilizer and other raw materials contain chemical additives, salt and other corrosive media, which have a greater corrosion effect on the ring die. The stainless steel ring die can perform better than the alloy steel ring die and increase the output. However, wood chips, sawdust, straw and other raw materials contain more impurities, and the hardness of the raw materials is high. Alloy steel has low carbon content, has high impact toughness, and has better wear resistance than stainless steel. The alloy steel ring die is selected. It is not easy to cause cracking of the ring die.

2. Ring die design and manufacturing process

The quality and service life of the ring die are related to not only the raw materials, but also to a large extent the design, processing and manufacturing, heat treatment and so on. Reasonable design of ring die, adopt appropriate heat treatment process according to different ring die materials to improve the mechanical properties of the ring die, improve its internal and external quality, and prolong the service life of the ring die.

3. Price difference

The price of the ring die varies from manufacturer to manufacturer, and the material standard, production process, processing equipment, and opening rate will also have certain differences; so the final price may have a lot of differences. Ring dies with low prices may use products with low material standards, relatively simple production processes, and low porosity. Such a product may eventually be a product with a relatively shortened service life of the ring die, low production efficiency, and high power consumption. In fact, the relative production cost will be greatly increased.

4. Compare the total production volume of ring die or loss cost per ton

In the case of the same production efficiency and production electricity consumption, it is meaningful to compare the total output of pellets produced by the ring die, or the cost of the ring die per ton loss.

How do we keep good quality of ring die / flat die?

1. More than 20years skilled experience for workers, and quality inspection for each process to ensure good quality.

2. Automated processing equipment to ensure good performance：More than 10 automatic CNC gun drilling machines+ CNC lathe machines+ CNC countersinking machines+ Heat treatment vacuum furnace.

3. Choosing China TOP1 JINKUN forging factory's raw material, usage life can be enhanced about 15%. Less impurities and high purity. Not have the problem of broken or crack.

4. New advanced holes' designing, ensure pellets/feeds can be made out smoothly, and special holes (row) arrangement, ensure the capacity can be enhanced 20% without broken.
