Ordinary Electronic Balance
Pellet Mill Dies
Roller Shell
This series of products screen compact bodies, neat and beautiful appearance, stable and reliable work, convenient operation and maintenance.
| Model | Roller Size(MM) | Slow roller | Fast roller speed(RPM) | Power | Capacity | Gross Weight (kg) | ||
|---|---|---|---|---|---|---|---|---|
| Dia. | Length | speed (RPM) |
(KW) | (T/H) | ||||
| Double Roller | SSLG15X80 | 150 | 800 | 476 | 725 | 4 | 2--4 | 650 |
| SSLG15X100 | 150 | 1000 | 476 | 725 | 5.5 | 3--6 | 750 | |
| SSLG15X150 | 150 | 1500 | 476 | 725 | 7.5 | 5--10 | 900 | |
| Three Roller | SSLG20X170 | 200 | 1700 | 360 | 470 | 15 | 10--15 | 1200 |
| SSLG25X170 | 250 | 1700 | 360 | 470 | 18.5+1.1 | 15--20 | 2100 | |
1. With triple - roller and double- roller structure: With the unique two-roll or three-roll different tooth shape differential speed principle realize the crumbling of pellets from φ1.5~φ6.0mm，which is high rate of finished products,less grade feed back.
2. Differential speed of crushing roller.The ideal crushing effect is achieved by squeezing, shearing and tearing of fast and slow rollers.
3. Unique hopper and bypass device. It not only plays the role of leveling material, but also plays the role of bypass flow for the material that does not need to be broken. When the bypass flow, automatic shutdown can be realized through the travel switch.
4. Narrow V v-belt drive.Smooth transmission, low noise, reliable operation, easy to operate.
5.Operate shunt plate (manual or pneumatic). Can make material does not need to be broken direct flow.
